CATIA V5-6R2015 Basics - Part II: Part Modeling - E-book - ePub

This book is a continuation of CATIA V5-6R2015-Part I. The topics covered in this book are listed below:Basic Sketch Based Features Pad Shaft Project 3D Elements The Plane command Offset from plane Parallel through Point Through three points Through two lines Through point and line Through planar curve Normal to curve Tangent to surface Equation Mean through points Coordinates On curve On Plane On Surface Circle/Sphere/Ellipse center Tangent on curve Between Line Additional options of the Pad and Pocket commands Limits Thick View commands Measure Commands Holes and Dress-Up Features   Hole Simple Hole Counterbored Hole Countersunk Hole Tapered Hole Threaded Hole The Thread/Tap command The Edge Fillet command Limiting element(s) Blend corner(s) Variable Radius Fillet Chordal Fillet Face-Face Fillet Tritangent Fillet The Chamfer command Draft Angle Draft Reflect Line Variable Angle Draft Shell      Patterned Geometry The Mirror command Rectangular Pattern Circular Pattern User Pattern Scaling Affinity Rib Features The Rib command The Slot command Multi Section Solids The Multi-sections Solid command Types of the Cross-sections Couplings Spines Guides Relimitation Removed Multi-sections Solid Additional Features and Multibody Parts Stiffener Solid Combine Multi-body Parts Creating Multi-bodies Insert in new body Assemble Add Remove Intersect Union Trim Remove Lump   Modifying Parts     Edit Sketches Edit Feature Definition Edit Feature Parameters               Deactivate Features Activate Features Changing the Sketch Support
