DIY 7.4kW Home EV Charger_EDP-01A
Par :Formats :
Actuellement indisponible
Cet article est actuellement indisponible, il ne peut pas être commandé sur notre site pour le moment. Nous vous invitons à vous inscrire à l'alerte disponibilité, vous recevrez un e-mail dès que cet ouvrage sera à nouveau disponible.
Disponible dans votre compte client Decitre ou Furet du Nord dès validation de votre commande. Le format ePub est :
- Compatible avec une lecture sur My Vivlio (smartphone, tablette, ordinateur)
- Compatible avec une lecture sur liseuses Vivlio
- Pour les liseuses autres que Vivlio, vous devez utiliser le logiciel Adobe Digital Edition. Non compatible avec la lecture sur les liseuses Kindle, Remarkable et Sony
, qui est-ce ?Notre partenaire de plateforme de lecture numérique où vous retrouverez l'ensemble de vos ebooks gratuitement
Pour en savoir plus sur nos ebooks, consultez notre aide en ligne ici
C'est si simple ! Lisez votre ebook avec l'app Vivlio sur votre tablette, mobile ou ordinateur :
- FormatePub
- ISBN8230586203
- EAN9798230586203
- Date de parution04/04/2025
- Protection num.pas de protection
- Infos supplémentairesepub
- ÉditeurIndependently Published
Résumé
This eBook is DIY (DO IT YOURSELF) type practical electronics product manufacturing eBook written by a highly expert IIT Engineer. You will be able to Build Your Own "Home EV Charger - Type 2 - 7.4kW - 230V AC - Single Phase - LED Display" with the help of this eBook only and you do not need to consult anyone else. This eBook has Complete Design Package which includes 7 (Seven) well explained Chapters, 19 Downloadable Resources Design Files, 66 Engineering Images, Downloadable Gerber Files for 6 PCB's, Complete Bill of Materials, Complete Manufacturing Files for Model: EDP-O1A, Calibration & Test Procedures for the Model: EDP-01A.
This eBook provides everything you need to construct a robust and reliable Home EV charger, suitable for personal use or commercial distribution. It's built upon a design rigorously tested with actual electric vehicles, ensuring its practicality and effectiveness. Dive into seven meticulously detailed chapters, each packed with essential design and engineering data. Chapter 1 introduces you to the core technology of electric vehicle chargers, laying the foundation for your understanding.
Chapter 2 outlines the product's technical specifications, providing a clear roadmap for your project. Chapter 3 presents a comprehensive Block Diagram of the home EV charger, simplifying the complex system into manageable components. The heart of the design is unveiled in Chapter 4, focusing on the motherboard. Here, you'll find detailed schematics, PCB designs with downloadable Gerber files, a complete Bill of Materials (BOM), and the necessary Arduino codes.
Chapter 5 extends this detail to other critical components, including safety interlock cards, RFID access control cards, and Bluetooth access control cards, each with the same level of comprehensive documentation. Chapter 6 guides you through the manufacturing process, covering door plate and mounting plate interconnections, EV charger simulator fabrication, mobile app details, and the creation of manufacturing smart cards.
Finally, Chapter 7 provides detailed calibration and test procedures, ensuring your finished product meets the highest standards of performance and safety. This eBook is designed to be accessible, using plain language to demystify complex engineering concepts. You'll receive 16 downloadable resource design files, 59 engineering images, and Gerber files for six PCBs, alongside complete manufacturing files and calibration procedures for the EDP-01A model.
Whether you're a young engineer, a seasoned professional, or an engineering student seeking a graduation project, this eBook provides the knowledge and resources to confidently build a 7.4kW AC Home EV Charger. No design modifications are required; simply follow the step-by-step instructions. A basic understanding of electronics product construction is beneficial. Purchase this eBook and embark on a rewarding journey of building your own fully tested, marketable EV charger.
For start-ups, this represents an excellent entry point into electronics product manufacturing. Transform your knowledge into a tangible, working product, and take a significant step towards the future of sustainable transportation.
