DIY Fast EV Charger 22kW
E-book
33,99 €
DIY 7.4kW Domestic EV Charger_EDP - 01B
Par :Formats :
Disponible dans votre compte client Decitre ou Furet du Nord dès validation de votre commande. Le format ePub est :
- Compatible avec une lecture sur My Vivlio (smartphone, tablette, ordinateur)
- Compatible avec une lecture sur liseuses Vivlio
- Pour les liseuses autres que Vivlio, vous devez utiliser le logiciel Adobe Digital Edition. Non compatible avec la lecture sur les liseuses Kindle, Remarkable et Sony
, qui est-ce ?Notre partenaire de plateforme de lecture numérique où vous retrouverez l'ensemble de vos ebooks gratuitement
Pour en savoir plus sur nos ebooks, consultez notre aide en ligne ici
C'est si simple ! Lisez votre ebook avec l'app Vivlio sur votre tablette, mobile ou ordinateur :
- FormatePub
- ISBN8230262954
- EAN9798230262954
- Date de parution04/04/2025
- Protection num.pas de protection
- Infos supplémentairesepub
- ÉditeurIndependently Published
Résumé
This is a DIY or "Do-It-Yourself type" practical electronics product manufacturing eBook written by a highly expert IIT Engineer. You will be able to Build Your Own "Domestic EV Charger - Type 2 - 7.4kW - 230V AC - Single Phase-LCD Display" with the help of this eBook only and you do not need to consult anyone else. This eBook has Complete Design Package to build an EV Charger for your personal use or a Marketable Product.
The addition of a Nextion - 3.5" TFT LCD Display to show user friendly images to the user during the EV Charger operation has added a useful & attractive aesthetic to the product. This design is fully tested in actual electric car. This is probably the only available book with complete design resources having 7 (Seven) well explained Chapters, 19 Downloadable Resources Design Files, 71 Product Design Images, Downloadable Gerber Files for 6 PCB's, Complete Bill of Materials, Complete Manufacturing Files and Calibration & Test Procedures for the Model: EDP-01B.
Chapter 1 introduces you to the core technology of electric vehicle chargers, laying the foundation for your understanding. Chapter 2 outlines the product's technical specifications, providing a clear roadmap for your project. Chapter 3 presents a comprehensive Block Diagram of the Domestic EV charger, simplifying the complex system into manageable components. The heart of the design is unveiled in Chapter 4, focusing on the motherboard.
Here, you'll find detailed schematics, PCB designs with downloadable Gerber files, a complete Bill of Materials (BOM), and the necessary Arduino codes. Chapter 5 extends this detail to other critical components, including safety interlock card, Nextion Driver Card, RFID access control card, and Bluetooth access control card, each with the same level of comprehensive documentation. Chapter 6 guides you through the manufacturing process, covering Nextion display Images and relevant files, door plate and mounting plate interconnections, EV charger simulator fabrication, mobile app details, and the creation of manufacturing smart cards.
Finally, Chapter 7 provides detailed calibration and test procedures, ensuring your finished product meets the highest standards of performance and safety. This eBook is designed to be accessible, using plain language to demystify complex engineering concepts. Whether you're a young engineer, a seasoned professional, or an engineering student seeking a graduation project, this eBook provides the knowledge and resources to confidently build a 7.4kW AC Domestic EV Charger.
No design modifications are required; simply follow the step-by-step instructions. A basic understanding of electronics product construction is beneficial. Buy this Book and just follow all the steps. When all the Steps are finished, you'll have a Fully Tested working model of a marketable 7.4kW Domestic EV Charger. For 'Start-ups", it's a good start in Electronics Product Manufacturing. Even professional engineers will find it highly useful to get a complete knowledge about EV Chargers.
