Build and Study RS, D, JK, and T Flip Flops Using TTL Logic Gates
This eBook guides you to build and study flip-flops using TTL logic gates with logic gate ICs 74LS00, 74LS02, 74LS04, 74LS08, and 74LS11. A flip-flop is a digital memory device that stores one bit of data either logic 0 or logic 1, and they are the primary blocks of most sequential circuits. The term Bistable multivibrator or one-bit memory device is also used to refer to a flip-flop. Topics covered are Bistable Multivibrator, Reset-Set Latch, Reset-Set flip-flop, JK flip-flop, Data flip-flop, and Toggle flip-flop using TTL logic gate integrated circuits (ICs).
The book illustrates each 'latch' and 'flip-flop' with a schematic diagram and explanation and practically verifies the truth table of each flip-flop. Each circuit includes a breadboard wiring diagram. The eBook provides a practical 'hands-on learning experience' to the engineers, technicians, students, and hobbyists who are curious and eager to learn and conduct experiments on their own. The chapters in the eBook explains all the relevant topics in a simple and descriptive manner for you. Building these electronic circuits rapidly boosts your skills and analytic power to a great level, and thousands of applications use it, making it extremely popular. The eBook includes a brief Theory, Logic Symbols, Truth Tables, Circuit Diagrams, Circuit descriptions, and Parts List.
The eBook also includes Breadboard Wiring Diagrams, actual Photos of Electronic Components, Pin diagrams, and Polarity, color codes of Components, and Capacitor Value Conversion Tables.
